170" SPRINTER / 148" EXTENDED TRANSIT

SHASTA LAYOUT

SEAT 2-4 / SLEEP 2

Banner Image

2023 MERCEDES SPRINTER AWD 170WB

Seat 4 / Sleep 3

This Shasta Layout has some custom seating from Alpine Van Works that can turn 90 degrees on a swivel and folds into a bed with the front seat! The build was designed for Full-time living for 2 and space for the college-age son when he wants to tag along.

This rig is fully prepared for any weather with 4 season insulation, heated floors, AC, and an extended-range fuel tank to run that heat for days on end. Where to next?

  • Warm and Homey Color Scheme
  • Easy-to-Clean Vinyl Walls
  • Interior Shower and Toilet
  • Double Burner Cooktop
  • POWER: 945AH Lithionics Power Battery Bank with second Nations Alternator
  • COOLING: Nomadic Cooling X3 AC
  • HEATING: Aqua Hot heat & hot water with floor heat (diesel fired)
  • WATER: 30 Gallons of Fresh Water & 15 Gallons of Gray + Interior & Exterior Shower
  • Tanner Rack Safari Rack, Ladder and Running Boards
  • Backwoods Scout Bumper
  • Agile Rip Kit Suspension
  • 32.5" AT Tires & Owl Wheels

Morris

2023 MERCEDES SPRINTER AWD 170WB

Seat 2 / Sleep 2

This incredible rig was specifically designed for months away from home without sacrificing any creature comforts. From the slide-out Jura E8 Espresso Maker to the lighted and replaceable wall art backsplash, this van has it all!

And. . .did we mention the exterior? Designed for surfing, kiting, biking, backcountry, and whatever else you may find yourself doing while traveling through North America.

  • Integrated Jura E8 Espresso Maker
  • Custom Lighted Picture Frame Backsplash (Changeable)
  • Designed for Full-Time Use
  • EPIC Sound System
  • POWER: 800ah 12V System with secondary Nations Alternator & 3200W Inverter
  • COOLING: Nomadic Cooling x3
  • HEATING: AquaHot Heat & Hot Water(diesel fired)
  • WATER: 30 Gallons of Fresh Water & 11 Gallons of Gray + Exterior and interior Shower
  • SUSPENSION: Agile Rip Kit & Running Boards, ARB Air Compressor + 33” Tires with quick deflate valves
  • Roambuilt Safari Rack with LP9’s, Ladder & Running Boards.
  • CA Tuned Bumper with Warn Synthetic Winch
  • Owl Vans Rear Box & Bike Rack
  • Backwoods Rear Bumber

Tom

2022 MERCEDES SPRINTER 4X4 170WB

Seat 2 / Sleep 2

The Steel Blue van with yellow pinstriping is a nod to the Blue Angels as the owner of this awesome rig is a pilot. This build was designed for month-long trips across the US and Canada with AC, 800AH of Victron Power, custom Inhabit Floor mats, and much more!

One pecuiare feature of this van is the large closet that houses the Laveo Dry Flush Toilet. This allows enough room to sit and have privacy on the toilet, but also keep dry closet storage.

  • Homey Modern Color Scheme
  • Easy-to-Clean Vinyl Walls
  • Interior Convertible Shower
  • Double Burner Cooktop
  • POWER: 800AH Victron Power Battery Bank with second Nations Alternator
  • COOLING: Nomadic Cooling 3000 AC
  • HEATING: Timberline heat & hot water(diesel fired)
  • WATER: 30 Gallons of Fresh Water &11 Gallons of Gray + Interior & Exterior Shower
  • Tanner Rack Safari Rack, Ladder and Running Boards
  • Flarespace Flares
  • Backwoods Nomad Bumper
  • Van Compass 4.3 Adjustable Suspension
  • 31.5" Tires & Black Rhino Wheels

2022 MERCEDES SPRINTER 4X4 170WB

Seat 2 / Sleep 2

This big red sprinter is ready for just about anything with a 10KW Volta pack, Murphy bed, secondary sleeping at the convertible dinette, and a super open layout with windows all around. Combine that with the rugged features on the exterior there isn't a single place this rig won't look good!

  • Fire Engine Red Theme
  • Easy-to-Clean Vinyl Walls
  • Interior Convertible Shower
  • Murphy Bed
  • Under-Counter Laveo Dry Flush Toilet
  • POWER: 10KW Volta Power Pack and Secondary 7KW Alternator
  • COOLING: Dometic Penguin AC
  • HEATING: Timberline heat & hot water(diesel fired)
  • WATER: 30 Gallons of Fresh Water &11 Gallons of Gray + Interior & Exterior Shower
  • Flatline Van Co Low Pro Rack and Ladder
  • Backwoods Nomad Bumper
  • Van Compass 4.3 Adjustable Suspension
  • Hood Wrap
  • 31.5" Tires & Black Rhino Wheels

2021 MERCEDES SPRINTER 4X4 170WB

Seat 4 / Sleep 2

This Shasta Layout has some custom seating that can turn 90 degrees on quick-release brackets. The build was designed for month-long trips across the US and Canada with AC, Volta Power, custom Inhabit Floor mats, and much more!

  • Inhabit Designs Removable Floor Mats
  • Signature Bamboo ceiling
  • Sheel-mann Seats
  • Murphy Bed with "Standing Desk Mode"
  • Isotherm 130L Fridge
  • Heated Floors
  • Modular Seating
  • POWER: 10KW Volta 48V Pack with second 7KW alternator & 3200W Inverter and 300W solar
  • COOLING: 48V Cruise N Comfort Air Conditioning
  • HEATING: Timberline heat & hot water(diesel fired)
  • Water: 42 Gallons of Fresh Water &11 Gallons of Gray + Interior & Exterior Shower
  • PERFORMANCE: Pedal Box Instant Tune
  • Flatline Low Pro Rack
  • AMP Research Auto Running Boards
  • Backwoods Adventure Mods Bumper
  • Warn Synthetic Winch
  • Owl Vans Sherpa and Bike Rack
  • Fiamma Automatic Awning
  • Van Compass 4.3 Suspension
  • ARB Air Compressor
  • 31" Tires & Black Rhino Wheels

2020 MERCEDES SPRINTER 4X4 170WB

Seat 2 / Sleep 2

This Shasta Layout is built in a black-on-black 170 Sprinter with tons of attitude on the exterior and a warm homey build on the inside. The huge amounts of storage and counter space make it perfect for full-time living, even though this client didn't want an interior shower.

  • Sileather - Vegan Leather Walls and Ceiling
  • Warm Mahogany Color Cabinets with Richlite Counter
  • Murphy Bed
  • Propane Stove and Oven
